A new sequence of Hubble Space Telescope images of the remnant of a tremendous stellar explosion is giving astronomers a remarkable look at the dynamic relationship between the tiny Crab Pulsar and the vast nebula that it powers.
The colorful photo on the left shows a ground-based image of the entire Crab Nebula, the remnant of a supernova explosion witnessed over 900 years ago. The nebula, which is 10 light-years across, is located 7,000 light-years away in the constellation Taurus. The green, yellow and red filaments concentrated toward the edges of the nebula are remnants of the star that were ejected into space by the explosion.
At the center of the Crab Nebula lies the Crab Pulsar – the collapsed core of the exploded star. The Crab Pulsar is a rapidly rotating neutron star – an object only about six miles across, but containing more mass than our Sun. As it rotates at a rate of 30 times per second the Crab Pulsar's powerful magnetic field sweeps around, accelerating particles, and whipping them out into the nebula at speeds close to that of light.
The blue glow in the inner part of the nebula – light emitted by energetic electrons as they spiral through the Crab's magnetic field – is powered by the Crab Pulsar.
The picture on the right shows a Hubble Space Telescope image of the inner parts of the Crab. The pulsar itself is visible as the left of the pair of stars near the center of the frame. Surrounding the pulsar is a complex of sharp knots and wisp-like features. This image is one of a sequence of Hubble images taken over the course of several months. This sequence shows that the inner part of the Crab Nebula is far more dynamic than previously understood. The Crab literally "changes it stripes" every few days as these wisps stream away from the pulsar at half the speed of light.
The Hubble Space Telescope photo was taken Nov. 5, 1995 by the Wide Field and Planetary Camera 2 at a wavelength of around 550 nanometers, in the middle of the visible part of the electromagnetic spectrum.
Credits
Jeff Hester and Paul Scowen (Arizona State University) and NASA| About The Object | |
|---|---|
| Object Name | Crab Nebula |
| R.A. Position | 05h 34m 31.96s |
| Dec. Position | 22° 0' 52.09" |
| About The Object | |
|---|---|
| Object Name | A name or catalog number that astronomers use to identify an astronomical object. |
| Object Description | The type of astronomical object. |
| R.A. Position | Right ascension – analogous to longitude – is one component of an object's position. |
| Dec. Position | Declination – analogous to latitude – is one component of an object's position. |
| Constellation | One of 88 recognized regions of the celestial sphere in which the object appears. |
| Distance | The physical distance from Earth to the astronomical object. Distances within our solar system are usually measured in Astronomical Units (AU). Distances between stars are usually measured in light-years. Interstellar distances can also be measured in parsecs. |
| Dimensions | The physical size of the object or the apparent angle it subtends on the sky. |
| About The Data | |
| Data Description |
|
| Instrument | The science instrument used to produce the data. |
| Exposure Dates | The date(s) that the telescope made its observations and the total exposure time. |
| Filters | The camera filters that were used in the science observations. |
| About The Image | |
| Image Credit | The primary individuals and institutions responsible for the content. |
| Publication Date | The date and time the release content became public. |
| Color Info | A brief description of the methods used to convert telescope data into the color image being presented. |
| Orientation | The rotation of the image on the sky with respect to the north pole of the celestial sphere. |
